High Density LC SC Breakout Fiber Optic Cable Assembly – 12/24/36/48/72/96/144 Core
High Density LC SC Breakout Fiber Optic Cable Assembly – 12/24/36/48/72/96/144 Core Decription
Takfly is one of the largest and best breakout fiber optic cable assembly – 12/24/36/48/72/96/144 core manufacturers and suppliers with rich experience. Welcome to buy our high quality products or wholesale our customized breakout fiber optic cable assembly – 12/24/36/48/72/96/144 core in stock with our factory. Also, sample is also available if necessary.
The 12/24/36/48/72/96/144 Core Breakout Fiber Optic Cable Assembly is engineered for high-density FTTH, FTTx, and telecom networks.
This assembly splits multi-core ribbons into individual fiber units for direct termination or integration into patch panels.
Its robust PVC/LSZH jacket and high-performance connectors ensure minimal loss and maximum reliability across demanding environments.
High Density LC SC Breakout Fiber Optic Cable Assembly Application
Ø CATV
Ø Telecommunication networks
Ø Active device termination
Ø Local area networks(LANS)
Ø Data processing networks
Ø Test equipment
Ø Wide area networks(WANS)
High Density LC SC Breakout Fiber Optic Cable Assembly Features
Ø Low insertion loss and High reflection loss
Ø Good exchange ability
Ø Good durability
Ø High temperature stability
Ø Standard:Telcordia GR-326-CORE
High Density LC SC Breakout Fiber Optic Cable Assembly Specification
|
Connector Type
|
LC
|
|
End face type
|
APC
|
| Fiber Type |
SM G652D, SM G657A1, SM G657A2 |
|
Cable Diameter
|
10.5mm
|
|
Insertion loss
|
≤ 0.3 dB
|
|
Return loss
|
UPC SM≥50dB , APC SM ≥60dB
|
|
Repeatability
|
≤ 0.1
|
|
Durability
|
≤ 0.2dB
|
|
Interchangeability
|
≤ 0.2dB
|
|
Tensile strength
|
>70N
|
|
Operating Temperature
|
-20℃~70℃
|
|
Storage Temperature
|
-40℃~80℃
|
|
Outer Sheath Material
|
LSZH
|
|
Bending radius(Static/Dynamic)
|
10D/20D
|
|
Length
|
10M, 20M, 50M, 100M or customized
|
|
Fanout Length
|
0.5M , 1M or customized
|
|
Fanout Diameter
|
2.0mm
|
How to order fiber optic patchcord?
1. Connector type : SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
2. Mode type : single mode ( UPC and APC ) / multi mode ( PC )
3. Cable diameter : 0.9 / 2.0 / 3.0 mm ( can customized other diameter )
4. Coating material : PVC / LSZH
5. fiber count : simple / duplex / 4 core / 6core / 8 core /12 core / 24core/48 core / 96 core and so on
6. Cable type : G652D / G657A1 / G657A2 /G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 /OM5
7. Patch cord length : according to your requirement
8.MPO/MTP connector should let us know which method ( A type / B type /C type ), male or female , fiber count (4/8/12/16/24/32/48/72/96/144/288 fiber )
